IP8820/IP8830/IP8840
Installer Guide
D-8
Section
Field Name
Description
line1_name ~
linen_name
Defines the SIP user id that is often a number or SIP address
for use when registering. Enter a number without dashes,
enter 555-0100 as 5550100, or a SIP address without the
host name.
The n variable is the line button and can be from 1 to the
max_line_num.
Valid value is up to 50 characters.
The default is blank.
line1_authname ~
linen_authname
Specifies the name for authentication if the proxy server
challenges the line registration. It is required only if a proxy
server requires authentication.
The n variable is the line button and can be from 1 to the
max_line_num.
Valid value is up to 50 characters.
The default is blank.
line1_password ~
linen_password
Specifies the password for authentication if the proxy server
challenges the line registration.
The n variable is the line button and can be from 1 to the
max_line_num.
Valid value is up to 50 characters.
The default is blank.
line1_type ~
linen_type
Defines the type of line. The n variable is the line button and
can be from 1 to the max_line_num.
Valid values are as follows:
• private: Calls to the line are presented to all appearances
of the line but, an active call is visible and accessible
through the original endpoints involved in setting up the
call.
• shared (MADN): Calls to the line are presented to all call
appearances of the line and all calls are visible and
accessible by the authorized set of endpoints.
• DSS/BLF: The line button displays status (idle or busy)
and provides one-button calling to the extension.
Presence (BLF) and the linen_extension parameters
must be assigned. Also, do not assign an Auth Name
and Password.
Default is private.
line1_dn ~
linen_dn
Specifies the directory number. Lines assigned as the shared
type (linen_type) require assignment of the associated DN.
The n variable represents the IP Phone flexible button
number for the line.
Valid value is a string of up to 50 characters.
The default is blank
line1_extension ~
linen_extension
When the line type is DSS/BLF, the associated extension
number must be assigned. The n variable is the line button
and can be from 1 to the max_line_num.
The valid value is the extension number.
The default is blank.
