3-59
Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
(4)-6 How to specify the channel to copy trigger settings
1. Select a level value in the START source setting or STOP source setting on the “TRIG” tab.
2. Open the level settings.
3. Start copying settings.
4. Select the source CH. The source CH will be marked with a “*” mark.
If you select the same CH again, the copy source will be cancelled.
5. Specify the copy destination. The copy destination CH will be marked with a “>” mark.
You can specify multiple copy destinations, and specifying a CH again will remove it from the copy destination.
Only copyable channels can be selected.
To Next Page
