3-37
Chapter 3 Settings and Measurement
Contents General Description
Checks and Preparation
Settings and Measurement
Example of Use Specification
Decimal point position Max Min
Four decimal places +9.9999 -9.9999
Three decimal places +99.999 -99.999
Two decimal places +999.99 -999.99
One decimal place +9999.9 -9999.9
Five-digit integer +99999. -99999.
If the calculation result is outside the valid range, change the decimal point position.
Copy settings
Copy the AMP settings of the specified CH to any CH.
(1)-14 Copy Contents
Item Supplement
Analog CH Input
Sensor
Range
Filter
EU
Span
Trace
Trigger Select whether to copy or not in the copy options.
Level value only.
Alarm Select whether to copy or not in the copy options.
Level value and output number.
Logic Filter
Trace
Trigger Select whether to copy or not in the copy options.
Level value only.
Alarm Select whether to copy or not in the copy options.
Level value and output number.
Pulse Input
Filter
Slope
EU
Span
Trace
Pulses per revolution
Trigger Select whether to copy or not in the copy options.
Level value only.
Alarm Select whether to copy or not in the copy options.
Level value and output number.
Calculation Calculation Off, Calculation formula, 4-point input
Calculation formula CH-X,Y For setting the calculation formula
Coefficient a,b/Constant c For setting the calculation formula
Operator For setting the calculation formula
Scaling For setting the calculation formula
CH-X For 4-point input
Measured value Upper limit/Lower limit For 4-point input
Calculated value Upper limit/Lower limit For 4-point input
Decimal point For 4-point input
Span Upper limit/Lower limit/Decimal point The decimal point is the same as when entering 4 points.
Unit
Trace
Trigger Select whether to copy or not in the copy options.
Level value only.
Alarm Select whether to copy or not in the copy options.
Level value and output number.
To Next Page
