3-20
To do… Use the command... Remarks
Clear the statistics information of all kinds
of MLD messages learned by MLD
snooping
reset mld-snooping statistics
Available in user view
z The reset mld-snooping group command works only on an MLD snooping–enabled VLAN.
z The reset mld-snooping group command cannot clear the MLD snooping multicast group
information for static joining.
MLD Snooping Configuration Examples
IPv6 Group Policy and Simulated Joining Configuration Example
Network requirements
z As shown in Figure 3-4, Router A connects to the IPv6 multicast source through Ethernet 1/0/2 and
to Switch A through Ethernet 1/0/1. Router A is the MLD querier on the subnet.
z MLDv1 is required on Router A, MLD snooping version 1 is required on Switch A, and Router A will
act as the MLD querier on the subnet.
z It is required that the receivers, Host A and Host B, attached to Switch A can receive IPv6 multicast
traffic addressed to IPv6 multicast group FF1E::101 only.
z It is required that IPv6 multicast data for group FF1E::101 can be forwarded through Ethernet 1/0/3
and Ethernet 1/0/4 of Switch A even if Host A and Host B accidentally, temporarily stop receiving
IPv6 multicast data.
Figure 3-4 Network diagram for IPv6 group policy simulated joining configuration
Configuration procedure
1) Enable IPv6 forwarding and configure IPv6 addresses
