2-23
Operation Command Description
Clear the statistics on NDP ports
reset ndp statistics [ interface
port-list ]
You can execute
the reset command
in user view.
When you display the cluster topology information, the devices attached to the switch that is listed in the
backlist will not be displayed.
Cluster Configuration Example
Basic Cluster Configuration Example
Network requirements
Three switches compose a cluster, where:
z An S3100 series switch serves as the management device.
z The rest are member devices.
Serving as the management device, the S3100 switch manages the two member devices. The
configuration for the cluster is as follows:
z The two member devices connect to the management device through Ethernet 1/0/2 and Ethernet
1/0/3.
z The management device connects to the Internet through Ethernet 1/0/1.
z Ethernet 1/0/1 belongs to VLAN 2, whose interface IP address is 163.172.55.1.
z All the devices in the cluster share the same FTP server and TFTP server.
z The FTP server and TFTP server use the same IP address: 63.172.55.1.
z The NMS and logging host use the same IP address: 69.172.55.4.
