H3C S3100 Series User Manual

2-4
Console Port Login Configuration
Common Configuration
Table 2-2 lists the common configuration of Console port login.
Table 2-2 Common configuration of Console port login
Configuration Remarks
Baud rate
Optional
The default baud rate is 9,600 bps.
Check mode
Optional
By default, the check mode of the Console port is set to
“none”, which means no check bit.
Stop bits
Optional
The default stop bits of a Console port is 1.
Console port
configuration
Data bits
Optional
The default data bits of a Console port is 8.
AUX user
interface
configuration
Configure the command
level available to the users
logging into the AUX user
interface
Optional
By default, commands of level 3 are available to the users
logging into the AUX user interface.
Make terminal services
available
Optional
By default, terminal services are available in all user
interfaces
Set the maximum number of
lines the screen can contain
Optional
By default, the screen can contain up to 24 lines.
Set history command buffer
size
Optional
By default, the history command buffer can contain up to
10 commands.
Terminal
configuration
Set the timeout time of a
user interface
Optional
The default timeout time is 10 minutes.
The change to Console port configuration takes effect immediately, so the connection may be
disconnected when you log in through a Console port and then configure this Console port. To
configure a console port, you are recommended to log into the switch in other ways. To log into a switch
through its Console port after you modify the Console port settings, you need to modify the
corresponding settings of the terminal emulation utility running on your PC accordingly in the dialog box
shown in
Figure 2-4.
Console Port Login Configurations for Different Authentication Modes
Table 2-3 lists Console port login configurations for different authentication modes.
