2-5
z To configure a Trunk port into a Hybrid port (or vice versa), you need to use the Access port as a
medium. For example, the Trunk port has to be configured as an Access port first and then a Hybrid
port.
z Ensure that the VLANs already exist before configuring them to pass through a Hybrid port.
z The default VLAN IDs of the Hybrid ports on the local and the peer devices must be the same.
Otherwise, packets cannot be transmitted properly.
Configuring a Trunk-Port-Based VLAN
A Trunk port may belong to multiple VLANs, and you can only perform this configuration in Ethernet port
view.
Follow these steps to configure the Trunk-port-based VLAN:
To do… Use the command… Remarks
Enter system view
system-view
Enter Ethernet port view
interface
interface-type
interface-number
Configure the port link type as
Trunk
port link-type
trunk
Required
Allow the specified VLANs to pass
through the current Trunk port
port trunk permit vlan
{ vlan-id-list |
all
}
Required
By default, all Trunk ports only
allow packets of VLAN 1 to pass.
Configure the default VLAN for the
Trunk port
port trunk pvid vlan
vlan-id
Optional
VLAN 1 is the default by default.
z To convert a Trunk port into a Hybrid port (or vice versa), you need to use the Access port as a
medium. For example, the Trunk port has to be configured as an Access port first and then a Hybrid
port.
z The default VLAN IDs of the Trunk ports on the local and peer devices must be the same.
Otherwise, packets cannot be transmitted properly.
Displaying and Maintaining Port-Based VLAN
To do… Use the command… Remarks
Display the hybrid or trunk ports
display port
{
hybrid
|
trunk
}
Available in any view.
