1-27
To do... Use the command... Remarks
Configure the specified ports as
edge ports
stp interface interface-list
edged-port enable
Required
By default, all the Ethernet
ports of a switch are non-edge
ports.
Configure a port as an edge port in Ethernet port view
Follow these steps to configure a port as an edge port in Ethernet port view:
To do... Use the command... Remarks
Enter system view
system-view
—
Enter Ethernet port view
interface interface-type
interface-number
—
Configure the port as an edge
port
stp edged-port enable
Required
By default, all the Ethernet
ports of a switch are non-edge
ports.
On a switch with BPDU guard disabled, an edge port becomes a non-edge port again once it receives a
BPDU from another port.
You are recommended to configure the Ethernet ports connected directly to terminals as edge ports
and enable the BPDU guard function at the same time. This not only enables these ports to turn to the
forwarding state rapidly but also secures your network.
Configuration example
# Configure Ethernet 1/0/1 as an edge port.
1) Configure Ethernet 1/0/1 as an edge port in system view
<Sysname> system-view
[Sysname] stp interface Ethernet 1/0/1 edged-port enable
2) Configure Ethernet 1/0/1 as an edge port in Ethernet port view
<Sysname> system-view
[Sysname] interface Ethernet 1/0/1
[Sysname-Ethernet1/0/1] stp edged-port enable
Setting the Link Type of a Port to P2P
A point-to-point link directly connects two switches. If the roles of the two ports at the two ends of a
point-to-point link meet certain criteria, the two ports can turn to the forwarding state rapidly by
exchanging synchronization packets, thus reducing the forward delay.
