1-25
Operation Command Description
Configure queue
scheduling
queue-scheduler { strict-priority |
hq-wrr queue0-weight queue1-weight
queue2-weight | wrr queue0-weight
queue1-weight queue2-weight
queue3-weight }
Required
By default, all the ports adopt the
WRR queue scheduling
algorithm, with the weights for
queues 0 to 3 as 1, 2, 3, and 4.
The SP queue scheduling algorithm is not available on H3C S3100-SI series Ethernet switches.
Configuration example
# Adopt the WRR queue scheduling algorithm, with the weight for queue 0, queue 1, queue 2, and
queue 3 as 12, 8, 4, and 1.
Display the configuration information after configuration.
Configuration procedure:
<Sysname> system-view
[Sysname] queue-scheduler wrr 12 8 4 1
[Sysname] display queue-scheduler
Queue scheduling mode: weighted round robin
weight of queue 0: 12
weight of queue 1: 8
weight of queue 2: 4
weight of queue 3: 1
Configuring Traffic Accounting
Only H3C S3100-EI series switches support this configuration.
Refer to section
Flow-Based Traffic Accounting for information about traffic accounting.
Configuration prerequisites
The ACL rules for traffic classification are defined. Refer to the ACL module of this manual for
information about defining ACL rules.
Configuration procedure
You can generate traffic statistics or clear traffic statistics on all the packets matching specific ACL rules,
or on packets that match specific ACL rules and are of a VLAN, of a port group, or pass a port.
