2-4
Network diagram
Figure 2-1 Network diagram for quick EAD deployment
Configuration procedure
Before enabling quick EAD deployment, be sure that:
z The Web server is configured properly.
z The default gateway of the user’s PC is configured as the IP address of the connected VLAN
interface on the switch.
# Configure the URL for HTTP redirection.
<Sysname> system-view
[Sysname] dot1x url http://192.168.0.111
# Configure a free IP range.
[Sysname] dot1x free-ip 192.168.0.111 24
# Set the ACL timer to 10 minutes.
[Sysname] dot1x timer acl-timeout 10
# Enable dot1x globally.
[Sysname] dot1x
# Enable dot1x for Ethernet 1/0/1.
[Sysname] dot1x interface Ethernet 1/0/1
