1-5
In PGV or PAFV mode, when a user fails MAC authentication on a port, the device adds the port to the
guest VLAN or Auth-Fail VLAN. Therefore, the guest VLAN can separate unauthenticated users on an
access port. When it comes to a trunk port or a hybrid port, if a packet itself carries a VLAN tag and the
VLAN is allowed on the port, the port will forward the packet according to the VLAN tag, regardless of
the guest VLAN or Auth-Fail VLAN. That is, packets can be forwarded to the VLANs other than the
guest VLAN or Auth-Fail VLAN through the Trunk or Hybrid port, even if users fail to pass
authentication.
Table 1-3 Configure a guest VLAN or Auth-Fail VLAN
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port view
interface interface-type
interface-number
—
Configure the guest VLAN for
MAC authentication
mac-authentication
guest-vlan vlan-id
Required
Not configured by default.
Configure the Auth-Fail VLAN
for MAC authentication
mac-authentication auth-fail
vlan authfail-vlan-id
Optional
Not configured by default.
Return to system view
quit
—
Configure the interval at which
the switch re-authenticates
users in guest VLANs
mac-authentication timer
guest-vlan-reauth interval
Optional
By default, the switch
re-authenticates the users in
guest VLANs at the interval of
30 seconds by default.
