H3C S3100 Series User Manual

1-6
z Layer 2 connectivity is ensured between the source and destination switches over the
remote-probe VLAN.
2) Configuration procedure
Table 1-5 Configuration on the intermediate switch
Operation Command Description
Enter system view
system-view
—
Create a VLAN and enter
VLAN view
vlan vlan-id
vlan-id is the ID of the
remote-probe VLAN.
Configure the current VLAN as
the remote-probe VLAN
remote-probe vlan enable
Required
Return to system view
quit
—
Enter the view of the Ethernet
port connecting to the source
switch, destination switch or
other intermediate switch
interface interface-type
interface-number
—
Configure the current port as
trunk port
port link-type trunk
Required
By default, the port type is
Access.
Configure the trunk port to
permit packets from the
remote-probe VLAN
port trunk permit vlan
remote-probe-vlan-id
Required
Configuration on a switch acting as a destination switch
1) Configuration prerequisites
z The destination port and the remote-probe VLAN are determined.
z Layer 2 connectivity is ensured between the source and destination switches over the
remote-probe VLAN.
2) Configuration procedure
Table 1-6 Configure remote port mirroring on the destination switch
Operation Command Description
Enter system view
system-view
—
Create a VLAN and enter
VLAN view
vlan vlan-id
vlan-id is the ID of the
remote-probe VLAN.
Configure the current VLAN
as a remote-probe VLAN
remote-probe vlan enable
Required
Return to system view
quit
—
Enter the view of the Ethernet
port connecting to the source
switch or an intermediate
switch
interface interface-type
interface-number
—
Configure the current port as
trunk port
port link-type trunk
Required
By default, the port type is
Access.
