Hammond SKX Reference Guide

Overdrive & Multi-Effects
186
Page 2 -DRAWBAR MULTI-EFFECTS
This Advanced Feature Menu Page allows you to select the Effects that will be added to the Drawbars when the
EFFECTS Touch Tab is “ON” (red LED lit).
Accessing the DRAWBAR MULTI-EFFECTS Menu Page using the Touch Buttons:
1. From either of the PLAY Screens, touch the MENU/EXIT Touch Button to see the first screen of the
MENU Mode. You will see “A" displayed in the extreme upper left corner of the Information Center
Display.
2. Touch the PAGE UP Touch Button two times. The legend “OD\EFF” in the upper left corner of the
Information Center Display will be blinking.
HA<O> SKX Owner’s Playing Guide

Hammond SKX Specifications

General

Manuals	2
Drawbars	9 per manual
Power Supply	AC Adapter
Effects	Chorus, Vibrato, Reverb
Connectivity	USB, MIDI, Audio Out, Headphones, Expression Pedal
Keyboard	61 keys (waterfall style)
Piano/Ensemble Section	Pianos, Strings, Brass
Display	LCD
Touch Sensitivity	Adjustable
