Hammond SKX Reference Guide

MIDI
318
Internal Zone Page 2 - Octave
From the previous screen, touch the PAGE RIGHT Touch Button once. Page 2 of the Internal Zone Edit Menu
should now display.
The legend just underneath the word “UPPER” should now blink.
Upper Octave Setting
This Advanced Feature Menu Page allows you to select the Octave range in which the Extra Voices will play. The
data chart below shows the options you may select.
UPPER Octave Options
Description Function
-2 The sound is two octaves below the regular pitch.
-1 The sound is one octave below the regular pitch.
0 The sound is at normal pitch.
+1 The sound is one octave above the regular pitch.
+2 The sound is two octaves above the regular pitch.
Turn the VALUE Rotary Control to the right to raise the Octave.
Turn the VALUE Rotary Control to the left to lower the Octave. It is linked with the [OCTAVE UP],
[OCTAVE DOWN] buttons on the top panel.
HA<O> SKX Owner’s Playing Guide

Hammond SKX Specifications

General

Manuals	2
Drawbars	9 per manual
Power Supply	AC Adapter
Effects	Chorus, Vibrato, Reverb
Connectivity	USB, MIDI, Audio Out, Headphones, Expression Pedal
Keyboard	61 keys (waterfall style)
Piano/Ensemble Section	Pianos, Strings, Brass
Display	LCD
Touch Sensitivity	Adjustable
