Overdrive & Multi-Effects
188
When accessing this Menu Page using the Shortcut, the Drawbar Effect shown in the Information Center
Display will be the one selected by the particular Patch that is active. This means that the Effect may be
different for different Patches.
The data chart shown below describes the different Drawbar Multi-Effects in the order in which they appear in
the Information Center Display.
DRAWBAR MULTI-EFFECTS
Description Function
Tremolo Raises and lowers the amplitude or volume at a determined rate.
Auto Pan Moves the sound back and forth between Left and Right channels.
Wah-Wah Adds and subtracts high frequencies.
Ring Modulation Merges two frequencies together to produce a bell-like sound.
Phaser Varies the phase relationship of two audio signals to each other.
Flanger Mixes two identical signals together, with one of them time-delayed by a small amount.
Chorus An enhancement to the sound similar to several instruments sounding in unison
Delay Recycles the tone to create an echo effect.
NOTE: Drawbar Effects are available on all organ types except the “Pipe” organ type.
Whether accessing this Menu Page using the Touch Buttons or the Shortcut, you can turn the VALUE Rotary Control
to select the effect you want to edit.
The next pages will describe the various Effects and the choices possible within each Effect.
HA<O> SKX Owner’s Playing Guide
