Alarm messages will be indicated by the buzzer and a message in the display. The following alarm messages
can be given:
Display 1st line Display 2nd line Explanation
DOOR FORCED
WARNING CLOSE DOOR Warning before DOOR HELD alarm.
DOOR HELD
NO ACCESS CARD BLOCKED
OUT OF TIME
ILLEGAL CARD
DOOR IS BLOCKED
CARD NOT CREATED
CODE MISUSE
CARD DATA ERROR
Card blocked by time program.
Not a THOR card data format
Door is blocked by Menu 71.
THOR intrusion code no. does not exist.
SYSTEM FAULT NO: 1: Communication problems with the THOR intrusion system.
Time and date NO COMMUNICATION No communication on the bus in a multi-reader / integrated
system.
DOOR IS OPEN SABOTAGE * Reader sabotage or sabotage from an S-ART soft type 07.
DOOR IS OPEN ALARM(S) * Alarm from an S-ART soft type 36.
DOOR IS OPEN SERVICE MODE Service is allowed on the system.
The alarm indication will disappear when the door is back in normal position and the message does not need to
be reset. The lines marked with * will also activate the - LED.
- Alarm message from an intrusion system.
If the reader is connected to a THOR intrusion system or if the input softtype 36 (alarm input from a non THOR
intrusion system) is defined in the reader programming and if the alarm system is in alarm condition then the
display will show an Alarm text, light the Alarm indicators and give a short buzzer every time the door is opened
from the reader. The text will be displayed until the alarm condition is reset on the THOR intrusion system or the
alarm condition on softtype 36 is reset.
