Technical Manual
October 1, 1995 18-006/081-04 GB
65
1.13 Event Logs.
The THOR access control system can log all events, for example: Passage through door, alarms and use of the
system. The log will show event name and type, time of event and card number.
2 types of logs are available:
♦
A local log containing all events including the alarms. Local means that only the events on this reader are
logged.
♦
A global alarm log containing only the events defined as alarms. Global means that the alarm log is
common for all the readers connected to the bus.
1.13.1 Local log (all events).
All events are consecutively numbered. All normal events are stored in a cyclic buffer in the THOR reader (max
2300 events). In case of overflow of these 2300 events, the first events are overwritten. This log is local for each
reader.
Different types of filters for the log
are available in the reader defined by time programs and /or personnel
groups, which together gives the possibility of limiting the number of irrelevant information in the log, thus
reducing the search time and unnecessary handling of old events.
Event Parameters
Door entry
Door Exit
Date shift "New date"
Set Alarm system
Unset Alarm system
Input test
Log-in
Log-out
Edit card
Delete card
Block card
Release card
Old time (change of time)
New time (change of time)
Execute menu
Card refused
Door closed (after door held)
Card no. Reader no.
(Card no.) Reader no.
Card no. Reader no.
Card no. Reader no.
S-ART no. Input status
Card no. Reader no.
Card no. Reader no.
Card no. Reader no.
Card no. Reader no.
Card no. Reader no.
Card no. Reader no.
Time date
Time date
Card no. Menu no.
Reader no.
Reader no.
All alarms are stored in a separate log with max. 100 alarms. This log is common for all readers. All local alarms
will also be shown in the events log.
