HI Sec THOR - Card Database

THOR Access Control
October 1, 1995 18-006/081-04 GB
50
The relations of the THOR access database are shown below and are explained in detail in the following:
Card database
Card number
PIN -code
Priority
Status
Pers. Grp. No.---->
Personnel Grp. database
Thor intrusion code number
Lock function? Yes/No
Hold - up code? Yes/No
Log normal access? Yes/No
Time program no.----->
Week Programs
Access rules:
Monday
................
................
Sunday
Access rules:
Special day 1
Special day 2
Card Reader Data:
Apart from these card related databases, there are defined some variables, which specify
the general function of the card reader. These parameters are defined in the "Mode" and "Options" programmed
during the initialization:
Stand alone / Multi reader system / Thor integration
4 or 6 digit PIN - code
Alarm reaction local / global.
External door control.
Local/Intrusion printer.
Real time printing.
External or indoor reader type.
Non-encrypted cards.
Address 1-15 or 16-31.
1.9.1 Card database.
The card database includes those data which are specific for the individual card.
In the basic version the THOR reader can store information for up to 1000 cards. In the expanded memory
version up to 12000 cards can be stored in the card database.
The card database contains the following information per card:
- Card number
- PIN code
- Status
- Priority
- Personnel grp. no.
