80 - Door release door 1 Active after accepted door release either by card or by the use of the exit
push-button. Involves activation of output softtype 83. Is reset when the
door opens or time-out. Is not sent externally.
81 - Door release door 2 Active after accepted door 2 release either by a card on an out-going
reader or by use of the exit push button 1 or 2 door 2. Involves activation
of output softtype 84. Is reset when the door opens or time-out.
1.4.3 Input addresses.
As each S-ART has 2 input addresses, it is necessary to calculate the relation between the S-ART address
(programmed on the S-ART board) and the input address (used when programming the input softtype) by the
following equation:
Input address = 2 x S-ART address + S-ART Input no. (0 or 1)
