Technical Manual
October 1, 1995 18-006/081-04 GB
27
42 - Emergency input Input to block interlocking doors. When the input is active the doors
connected to the corresponding reader will be blocked. Can also be used
on readers without interlocking function.
61 - External door contact The display will indicate DOOR IS OPEN when the input is active. Must
normally be connected to an output on the corresponding reader on
another bus programmed with the output softtype 86.
90 - 99 - IF input For free use. Must be incorporated in an IF/THEN equation. The softtype
is active when the input is active.
Logical Input Softtypes:
Logical input softtypes can only be used in IF/THEN equations. They are activated by a logical event in the
access unit, and cannot be assigned to a physical input.
70 - Door forced Active after the event - the door is forced open. Involves activation of
output softtype 70 and is reset when the door is closed. Is sent externally
as an alarm log message.
71 - Door held Active after the event - door held. Involves activation of output softtype 71
and is reset when the door is closed. Is sent externally as a alarm log
message.
72 - Door held warning Active when the door is held open too long time after door release.
Involves activation of output softtype 72 and is reset when the door is
closed. Is not sent externally.
73 - Card read Active when a card is read and accepted. Involves activation of output
softtype 73 and is reset when the door is closed or time-out. Is not sent
externally.
74 - Card misuse Active when a card is read with one of the following card status:
Card blocked
Card not released
Pin Code Error (10 times)
Involves activation of output softtype 74 and is reset when a legal card is
read or by time-out. Each event is sent externally as a separate alarm log
message.
76 - Time program Active when week program 32 is active.
controlled softtype
77 - Time program Active when week program 33 is active.
controlled softtype
78 - All cards out The input is active if all cards are registered in zone 00. The input is
passive if only one card is not in zone 00. The softtype can be
programmed in an IF/THEN equation.
79 - Hold-up code used Active when a hold-up PIN-code has been used. Involves activation of
output softtype 07 and is reset on time-out or upon a subsequent card
entry. Is sent as an external THOR hold-up message and as an alarm log
message.
