1.5.4 Activating types.
The activating types are used to activate outputs and are defined as follows:
Activating type : Delay / Duration /Polarity
The activating types are related to a physical output and not to a softtype, that means that outputs with the same
softtype can have different activating types.
Delay represents the time that passes from the softtype is activated to the physical output is activated. Duration
represents the max time during which the output is activated and polarity indicates whether the output is "Active
High" or "Active Low".
An output will always be reset when the softtype is reset (except the IF/THEN output soft types 90-94).
The THOR reader is preprogrammed from the factory with the following attributes. These
cannot
be changed
from the reader keyboard, but can only be changed from the AICS Configuration software:
Activating Type Delay Duration Polarity Description
1
2
3
0
0
0
∞
∞
∞
0
1
2
Permanent Off
Permanent On
Pulsating 1 sec.
4
5
6
0
0
0
3 min.
3 min.
3 min.
0
1
2
Permanent Off
Permanent On
Pulsating 1 sec.
7
8
9
0
0
0
5 sec.
5 sec.
5 sec.
0
1
2
Permanent Off
Permanent On
Pulsating 1 sec.
10
11
0
0
1 sec.
1 sec.
0
1
Permanent Off
Permanent On
1.5.5 Output addresses.
As each S-ART has 2 output addresses (only one is used), it is necessary to calculate the relation between the
S-ART address (programmed on the S-ART board) and the output address (used when programming the output
softtype) by the following equation:
Output address = 2 x S-ART address + S-ART Output no. (0 or 1)
With the existing S-ART type 90T S102 only output no. 1 can be used.
