1.5 Outputs.
1.5.1 Output types.
Outputs: The softtype indicates which input-actions will activate the output.
The activation type indicates the polarity of the output and possible time delay and time duration.
1.5.2 Output soft type description.
The output softtypes are divided into standard and special softtypes.
Standard output softtypes:
02 - Sabotage Local indication of sabotage alarm. Active if input type 07 is active.
(Common with intrusion).
07 - Hold-up Local indication of hold-up alarm. Active if input type 79 is active.
(Common with intrusion).
12 - Battery fault Local indication of battery fault. Active if input type 13 is active.
(Common with intrusion).
Special output softtypes:
20 - 35 - Zone Full This output softtype can be used to indicate f.ex. "parking full" in a parking
house. By the 90T AICS or 90T AMS software each zone can be
programmed with a max number of cards , which can be inside the zone.
When this number of cards inside the zone is reached, an output can be
activated. Output soft type 20 to 35 correspond to zone 0 to 15. Please
note that the door is
not
blocked when the max. number of cards inside
the zone is reached, and it is possible to enter more cards in the zone
than specified. The max. number specified for each zone only regards the
corresponding output.
40 - 69 - Elevator outputs Elevator output for controlling floor 1 to 30. Please see section 1.11
Elevator Outputs for further description.
70 - Door forced Local indication of door forced. Active if input softtype 70 is active.
71 - Door held Local indication of door held. Active if input softtype 71 is active.
72 - Door held warning A door held warning is indicated in the display and with the internal
buzzer. This output can be used to activate a warning lamp or a siren.
Active if input softtype 72 is active.
73 - Card entry Is active when a card is read. Active if input softtype 73 is active.
74 - Card misuse Local indication of Card Misuse. Active if input softtype 74 is active.
