2.7.2 90T HPMin antenna.
Technical Specifications:
Dimensions: 152 x 43 x 19 mm
Operating temperature: -30
0
C to +65
0
C
Power supply: 5 VDC, < 100 mA
Reading distance: Up to 10 cm depending on
mounting and transponder
type
Material: Black, high-impact ABS
plastic housing, two-
component polyurethane
filling compound.
J4 Jumper setting in 95T ERC: Open (Wiegand)
Max. distance between 95T ERC and antenna: 50 m shielded cable.
Connections:
Function Cable from antenna
90T HPMin
Terminal no. in
95T ERC
Flat-cable from terminal
90T RKP ERC
5 Volt Red 1 ( 5V ) 1 (red or blue)
Data Green 2 ( D0 ) 2
Clock White 3 ( D1 ) 3
0 Volt Black 4 ( 0V ) 4
Green LED Brown 6 ( LED2 ) 6
Red LED Orange 5 ( LED1 ) 7
