HI Sec THOR - HPP Antenna

THOR Access Control
October 1, 1995 18-006/081-04 GB
98
2.7.3 90T HPP antenna.
Technical Specifications:
Dimensions: 127 x 127 x 25 mm
Operating temperature: -30
0
C to +65
0
C
Power supply: 10-28.5 VDC, < 100 mA
Reading distance: Up to 14 cm depending on
mounting and transponder
type
Material: Black, high-impact ABS
plastic housing, two-
component polyurethane
filling compound.
J4 Jumper setting in 95T ERC: Open (Wiegand)
Max. distance between 95T ERC and antenna: 50 m shielded cable.
Connections:
Function Terminal no. in
antenna 90T HPP
Terminal no. in
95T ERC
Flat-cable from terminal
90T RKP ERC
+ DC 1
- DC 2
Data 3 2 ( D0 ) 2
Clock 4 3 ( D1 ) 3
0 Volt 5 4 ( 0V ) 4
Card detect not used not used 5
Green LED 6 6 ( LED2 ) 6
