Option 14: Exit without using an exit push button.
Option bit 14 = 1: No door forced alarms can be created from this reader. When the option bit is
1 the door handle can be used when going out of the door (no exit push button needed). If the
door is held too long time open an door held alarm will still be created.
Option bit 14 = 0: Door forced alarms will be created if the door is opened without reading a card
or using the exit push button.
Option 15: Real time printing using printer on main bus.
This option bit is only available on 95T reader types.
Option bit 15 = 1: The reader will use a printer on the main bus (bus 00) to print out events and
alarms (real time). NB: It is not possible to print out the programming on a printer on another
bus. Use this feature together with the log filters to minimize the amount of events printed out.
Option bit 15 = 0: The reader will use a printer on the local bus to print out events and alarms
(real time). This printer can also be used to print out the programming.
Card formats:
CFORM Card format
01 Hi Sec encrypted magstripe format
02 Hi Sec Wiegand format
03 Hi Sec Cotag prox./hands-free format
04 Hi Sec Hughes prox/hands-free format
05 Hi Sec non-encrypted magstripe format
06 Free programmable BCD code format (ISO 2) max. 16 digits (see below)
07 Special l'Oreal BCD magstripe format
08 Reserved for future use
09 Special La Chartre BCD magstripe format
10 Special Strassbourg city BCD magstripe format
11 Special Telemecanique old BCD magstripe format
12 Special Telemecanique new BCD magstripe format
13 Standard BCD magstripe format
14 Free programmable bit format (Wiegand) max. 64 bits (see below)
15 26 bit wiegand format, card no. first.
16 26 bit wiegand format, company code first. (ID Solutions)
17 Special Cotag format
