Technical Manual
October 1, 1995 18-006/081-04 GB
93
In the above connection diagram is shown an example with two 90T RKP ERC terminals, one 90T CDC double-
zone controller and one of each type of antenna. The same type of antenna for both antenna inputs can of
course also be used.
Note:
For the proximity antenna must be used two external 470 Ohm, ½W resistors to control the red and green
LED.
It is important to connect the two screens coming from the terminal and the double-zone controller together. This
is done in the 90T JB junction box.
The cable between the Cotag controller and the antenna must be with twisted pairs with a screen for
each pair.
Please note that the Double zone Controller
cannot
be used together with the Loop Coupler 90T CLC.
