9.2 Connection and Setting Procedures
126
6.
When “2: GP-IB“ is selected, press the key to move the flashing cur-
sor to the position of GP-IB address.
7.
Press the / keys to select the mode.
Setting range: 0 to 30 (Default setting: 3)
8.
Press the STOP key while holding down the SHIFT key to complete the
setting value.
The instrument reverts to the READY state.
To continue to the setting for the next item, press the key.
or
<Ex.> Select GP-IB Address 5
SHIFT
STOP
+
When both RS-232C and GP-IB are connected, signals without settings are
ignored.
