1.3 Names and Functions of Parts
13
1
Explanations on names and parts of Test Lead.
1.3.3 Model 9615 H.V.Test Lead
To prevent electric shock, when the DANGER lamp is lit or during the test,
never touch the voltage output terminals, test lead, or the tested object.
There is no insulation/withstand-voltage on the Alligator clip vinyl cover-
ing.
Tested object
9615 H.V.Test Lead
Alligator Clip
Connect to a test point on the test-
ed object.
Alligator Clip
High-voltage output plug
Connect to the HIGH voltage output
terminal on the instrument.
Low-voltage output plug
Connect to the LOW voltage output
terminal on the instrument.
