10.2 General Specifications
193
10
10.2 General Specifications
Test function Withstand-voltage test (50 Hz/60 Hz AC), Insulation-resistance test
Test mode Manual test mode: W/I
Auto test mode: W
→ I, I → W
Display Fluorescent tube display (digital display)
Monitor function Output voltage, Detected electric current, Insulation-resistance
Monitor cycle More than 2 times/second
Operating temperature
and humidity
0 to 40°C (32 to 104°F), 80%RH or less (no condensation)
Storage temperature and
humidity
-10 to 50°C (14 to 122°F), 90%RH or less (no condensation)
Temperature and
humidity range for
guaranteed accuracy
23±5°C (73 ±9°F), 80%RH or less (no condensation)
(after 10 minutes minimum warm-up)
Period of guaranteed
accuracy
1 year
Operating environment Indoors, Pollution degree 2, Up to 2000 m (6562-ft.)
Supply voltage 100 to 240 V AC (Voltage fluctuations of ±10% from the rated supply voltage
are taken into account.) (Anticipated transient overvoltage 2500 V)
Supply frequency 50/60 Hz
Dielectric strength 1.39 kV AC, 10 mA, 15 second between power supply and frame
Maximum rated power 200 VA
Dimensions Approx. 320W x 155H x 395D mm (12.60”W x 6.10”H x 15.55”D)
(not including protrusions)
Mass Approx. 15 kg (529.1 oz.)
Accessories Model 9615 H.V.Test Lead (high voltage side and return, 1 each)
Power cord (To be designated at the time of ordering, in accordance with the
powersupply voltage to be used)
Instruction manual
Slip Prevention Plate
Options Model 9615 H.V.Test Lead
Model 9151-02 GP-IB Connector Cable (2 m)
Model 9151-04 GP-IB Connector Cable (4 m)
Model 9267 Safety Test Data Management Software
Model 9637 RS-232C Cable (1.8 m, 9-pin to 9-pin)
Model 9638 RS-232C Cable (1.8 m, 9-pin to 25-pin)
Model 9613 Remote Control Box (Single)
Model 9614 Remote Control Box (Dual)
Model 9616 Warning Lamp
Applicable Standards EMC EN61326 Class A
EN61000-3-2
EN61000-3-3
Safety EN61010
