10.1 Basic Specifications
192
Contact check Makes the Contact Check function valid (no increase in tact time)
LOW side : if no electric current is detected during checks, a result of no con-
nection will appear
HIGH side : upper-limit and lower-limit detection voltages used in checks can
be set
When the Contact Check measurement voltage is higher than the
upper-limit value, or when it is smaller than the lower-limit value,
a result of power breakage will appear
Withstand test: voltage setting range 0.20 kV to 5.0 kV,
0.01 kV Resolution (common to both the upper and lower lim-
its)
Insulation-resistance measurement:
500 V; Upper Limit 600 V, Lower Limit 500 V
1000 V; Upper Limit 1200 V, Lower Limit 1000 V (
Fixed in all cases)
Accuracy of Voltmeter for
Contact Check
Detection method : Detection of average value and conversion to executable
value
Accuracy : Set value ±50 V
Note: When the waveform is distorted, the error margin may become bigger.
Key-lock function Ignores key inputs when set to Key Lock
Status Out Pre-set contact output in the Optional Function Screen
Maximum input voltage: 150 V AC, 30 V DC
Maximum contact current: 0.5 A
Insulation method: Mechanical Contact Relay
Output conditions
1 H.V.ON
2 TEST
3 PASS
4 FAIL
5 INT.LOCK
6 READY
7 EXT.CONT
8 POWER-ON
Note: ON output for rear panel relay contact with OR for respective valid con-
ditions
Other Functions
