10.3 H.V.Test Lead (Accessory) Specifications
194
10.3 H.V.Test Lead (Accessory) Specifications
Rated voltage High voltage side: 5 kV AC or 5 kV DC
Low voltage side : 600 V AC or 600 V DC
Rated current High voltage side: 150 mA AC or 150 mA DC
Low voltage side : 10 A AC or 10 A DC
Dielectric strength High voltage side: 6.25 kV AC, Sensitivity current 5 mA 1 minute
Low voltage side : 1.35 kV AC, Sensitivity current 5 mA 1 minute
Test point (between the core wire and the cable exterior)
Operating temperature
and humidity
0 to 40°C (32 to 104°F), 80%RH or less (no condensation)
Storage temperature and
humidity
-10 to 50°C (14 to 122°F), 90%RH or less (no condensation)
Operating environment Indoors, Up to 2000 m (6562-ft.)
Dimensions Approx. 1.5 m (59.06”)
Mass Approx. 100 g (3.5 oz.) (1 each for high voltage side and return side)
