3.4 Displaying the Test Result
45
3
Test is successful when lights up.
In the initial setting, will light up for about 0.3 seconds before returning to
READY mode.
When test time is set, PASS will appear when the test has completed.
If the ramp-down time is set, the reduction timer starts counting down the ramp-
down time. Upon expiration of the time, the measurement result upon completion
of the test is displayed, and the instrument changes to the PASS state. In the
PASS state, is lit.
3.4.1 "PASS" Determination
To hold the display
See "6.2.1 PASS Hold" (p. 85)
