11.4 System Reset
199
11
Procedure for System Reset
Turn ON the main power switch while pressing the SHIFT key.
Press and hold the SHIFT key until → → is shown.
Optional Functions
FAIL Hold, Double Action,
START protection function
1*
Output-voltage restricting value 5.0 kV *
PC interface 0
GP-IB address 3
Inter-lock 0
Interface command "START" 0
Others 0 *
Status Out
All 0 (Not set) *
Saved test conditions
Files in the withstand-voltage mode and insulation-resistance mode
will be initialized respectively.
Saved data
Results of the withstand-voltage test and the insulation-resistance
test will be initialized.
Contents to be reset Initial Values
