2.5 Turning the Power On and Off
25
2
Turning Power On
Turning Power Off
Front panel
1. Turn the power switch to on ( ).
2. The “3174” (model name) and software
version are displayed on the screen.
3. When the lamp is lit (it does not
light up in the Double Action mode), the
keys are ready for operation.
"6.1.3 Double
Action" (p. 81)
Model name
Software version
(This diagram shows version 1.00.)
State of interface
"rS.0": RS-232C 9600 bps
"rS.1": RS-232C 19200 bps
"G.XX": GP-IB address XX
Front panel
1. For safety reasons, check the following.
• Test has completed
•The DANGER lamp is off.
• The lamp is lit.
2. Turn the power switch to off ( ).
