Hioki 3174 - Page 36

30
W
Set test conditions
Select the Withstand-voltage test mode
"3.1.1 Setting the Test-Voltage Value" (p. 32)
"3.1.2 Setting the Upper (Lower) Limit Value" (p. 33)
"3.1.3 Setting the Test Time Timer" (p. 34)
"3.1.4 Setting the Ramp-up (Ramp-down) Time Timer" (p. 35)
"3.1.5 Setting the Test-Frequency" (p. 36)
"3.1.6 Setting the Initial voltage for ramp-up" (p. 37)
Starting a test
START
Displaying the test result
Press the START key to start a test. (p. 40)
PASS
Test result (p. 42)
