48
I
Select the insulation-resistance test mode
"4.1.1 Setting the Test-Voltage Value" (p. 50)
"4.1.2 Setting the Upper (Lower) Limit Value" (p. 51)
"4.1.3 Setting the Test Time Timer" (p. 53)
"4.1.4 Setting the Delay Time" (p. 54)
START
Press the START key to start a test. (p. 57)
PASS
Test result (p. 59)
Set test conditions
Starting a test
Displaying the test result
