7.11 Prepare the crane for use with the winch
11. Push the long shaft back into the top hole in the
hook block and through the hole in the cable
sheave.
l
The full hook block will be lifted.
12. Push the forks of the clamp keys together and
push the clamp keys back in.
13. Release the forks.
14. Make sure that the clamp keys are inserted and
locked correctly.
15. Turn the stop plates back in position.
User guide - C30e Compact crane 95
