HOEFLON C30e - Attaching the Hook Block

7.11 Prepare the crane for use with the winch
6. If you have the angle adapter set at -30°.
1. Remove the pin and the bracket.
2. Move the winch cable over the roll.
3. Put the pins and the bracket back in position.
7. Remove the pins and move the cable over roll in
the winch head.
8. Put the pin back in position.
9. You can now use the winch without reeving.
7.11.3 Attaching the hook block
1. Prepare the crane (see 7.11 Prepare the crane for use with the winch).
2. Set the remote control to use the winch (see 7.11.1 Identify the winch).
l
Set the Winch reeving factor to 1.
User guide - C30e Compact crane 87
