5.4 Display
No. Function Explanation
7 Outrigger angle - Right
Front
The angle between the outrigger and the centerline of the crane.
8 Outrigger is set correctly A green circle shows that the outrigger is correctly loaded.
9 Lifting capacity - Right The permitted lifting capacity in percent.
This value is determined by:
l
The angles of the outriggers.
l
The current Outreach radius.
l
The value given by the load chart (see Appendix)
10 Track is extended A green circle shows that a track is fully extended
11 Outrigger angle - Right
Rear
The angle between the outrigger and the centerline of the crane.
12 Lifting capacity - Rear The permitted lifting capacity in percent.
This value is determined by:
l
The angles of the outriggers.
l
The current Outreach radius.
l
The value given by the load chart (see Appendix)
13 Outrigger angle - Left
Rear
The angle between the outrigger and the centerline of the crane.
14 Lifting capacity - Left The permitted lifting capacity in percent.
This value is determined by:
l
The angles of the outriggers.
l
The current Outreach radius.
l
The value given by the load chart (see Appendix)
15 Digital bubble level The green circles indicate if the crane is level.
The number of degrees shows the tilt of the crane.
Use the spirit level on the crane to determine which direction the crane is
leaning.
5.4.2 Pick up mode
When the crane is in Pick up mode the letters PU are displayed in the top right corner of the display
Note
If no accessories or lifting attachments are installed then the crane is in "Pick up mode"
When the crane is in Pick Up mode it cannot lift or register a load.
User guide - C30e Compact crane 51
