HOEFLON C30e - Center of Gravity; With Jib

3. Technical data
2695
4295
1870
390
Note
The dimensions are:
l
with the jib attached.
l
with the tracks and the carrier arms extended.
l
with the winch in the upright position on the boom(see 8.12.1 Turn the winch
down next to the boom)
Note
The width of the crawler tracks can be set independently.
3.2 Center of gravity
3.2.1 With jib
Measured from:
369
1169
l
the center line of the slewing ring,
l
The bottom of the tracks when they are fully
retracted.
14 U.C30e.00.00.EN Version
