8.7 Lifting the load with the boom
Only use the boom for a lift if:
l
you are lifting a heavy load,
l
it is a relatively simple lift.
Use the lifting adapter and hook when you do a lift with the boom (see 4.3.1 Lifting adapter and hook)
8.7.1 Controls
Make sure that the superstructure is active (LED is ON).
RLFL RR FR
CBA
A. Rotate boom,
B. Extend / Retract boom,
C. Raise / lower boom.
(see 5.3.1 Default configuration)
8.7.2 Maximum angle of the boom when lifting with the hook
The maximum angle of the boom when you lift with the
hook is 65°
