5. Remote control
No. Function Explanation
2 Errors and warnings All errors and warnings are displayed here. An error has a red
background, a warning has a yellow background.
Caution
The crane will not continue with an error, you must
move the crane back to safety before you can
continue.
Note
Use the UP/DOWN arrow keys on the controller to
scroll between messages.
Use the LEFT/RIGHT arrow keys on the controller for
more information
3 Maximum load The maximum load that the crane can lift at this outreach and angle.
4 Load weight The current load hanging from the lifting hook.
5 Indicator for pick and
carry mode.
Tells the operator that the crane is in "Pick and carry" mode.
5.5 Connect with the crane
1. Start the crane and the remote control.
2. Make sure that the LED on button A is OFF.
Note
The remote control is already connected to a crane if the LED is ON.
58 U.C30e.00.00.EN Version
