HOEFLON C30e - Extending a Carrier Arm

7. Installation
16. Pull the large hook block out of its storage
position.
l
You use the large hook block during lifting
with 2x reeving.
Attaching the hook block with 4 x reeving
Note
Reeving four times is only possible with the jib 9.
See the jib 9 manual for more information.
7.12 Extending a carrier arm
1
2
1. Remove the clip.
2. Remove the pin
96 U.C30e.00.00.EN Version
