2. Safety
2.11 After work
l
Remove all attachments.
l
Put the crane in transport position , (see 11.1.1 Put the crane in transport position).
l
Remove the key before leaving the crane unattended.
l
Do not transport the crane unless the crane, outriggers and counterweight are completely
retracted, stowed and locked.
l
Remove all safety barriers and warning signs.
2.12 Emergency stop
The emergency stop button is:
l
At the rear of the crane.
l
On the remote control.
Caution
ONLY use in an emergency.
Do not use this button for ANY other reason.
Do not use the emergency stop to normally stop the crane.
Caution
Make sure that it is safe to start the compact crane.
2.13 Rated Capacity Limiter (RCL)
The RCL protects the compact crane from overloading.
When the crane is raised on the outriggers and the superstructure is active, the compact crane knows how the
weight is applied on the outriggers. The compact crane knows how much weight it can lift in any situation.
The compact crane also knows how much weight it can lift in any situation when it is in "Pick and Carry" mode
(see 8.11 "Pick and Carry" mode).
If the compact crane enters the range in which it is no longer allowed to lift the load, it will automatically stop
increasing the outreach. The red lamp in the stack light comes ON and the acoustic signal operates.
At this time the compact crane can only move the load so that it goes back into the safe range. The outreach is
reduced.
10 U.C30e.00.00.EN Version
