HOEFLON C30e - Main Components

4. Description
4.1 Main components
1 2 3 4
5
6
7
89101113 12
abcde
1. Boom sections
a. Main section 1
b. Section 2
c. Section 3
d. Section 4
e. Section 5
2. Arm to remove the counter weight
3. Hydraulic / electric reel
4. Winch
5. Stack lights
6. Counterweight
7. Outrigger
8. Rear compartment
9. Socket for the battery charger
10. Tracks
11. Front compartment
l
battery,
l
motor controller,
l
tank for hydraulic oil,
l
view glass for hydraulic oil.
12. hook block
13. Lift cylinder for the boom
20 U.C30e.00.00.EN Version
