5. Remote control
100 %
71 % 64 %
100 %
45 °
45 °
45 °45 °
0.2°
6.5 V
21
5 96
7
8
111213
1515 14
10
1
2
3
4
No. Function Explanation
1 Channel The communication channel that is used.
This may change when you start the remote control again.
2 Signal strength More bars > Better signal
Stop and start the remote control to select a different channel if the signal
is too weak.
3 State of charge of
remote control battery
More bars > More charge.
Replace the battery when only the red bar shows (see 5.6 Replacing and
charging the remote control battery)
4 Voltage The battery voltage of the remote control.
5 Outrigger angle - Left
Front
The angle between the outrigger and the centerline of the crane.
6 Lifting capacity - Front The permitted lifting capacity in percent.
This value is determined by:
l
The angles of the outriggers.
l
The current Outreach radius.
l
The value given by the load chart (see Appendix)
