2. Safety
Pictogram Meaning Location
l
Stay away from high-
voltage cables
l
Warning for hanging loads
l
Stay away from the crane
On the two sides of boom and the
jib.
Danger of crushing when operating
the counterweight
Stay away from the counterweight
On the cover at the rear of the
undercarriage.
Read the manual before operating
the crane
On the cover at the rear of the
undercarriage.
Stay away from the work area of
the crane
On the two sides of the cover at
the rear of the undercarriage.
Label that shows when annual
inspection is due (Netherlands
only)
On the right side of the cover of
the rear cabinet.
Risk of entrapment when setting
the outriggers
On the outriggers.
Warning for entrapment hazard On the crane at pivot points and
on the outriggers at the cylinders.
Warning for electrical voltage
l
On the HV box.
l
On the housing of the
motor controller.
Warning for non-ionising radiation On the left side of the boom near
the receiver.
