5. Remote control
Image Function Pull the lever rearward Push the lever forward
Lower / raise outrigger (RF –
front right)
Up Down
+
Extend / retract outrigger (RF
– front right)
Retract Extend
Superstructure
If the LED on button is ON, the levers operate the superstructure of the crane.
Image Function Pull the lever rearward Push the lever forward
Slew boom Left Right
Extend / retract boom Retract Extend
