5. Remote control
4. Put the discharged battery (2) in the battery
charger.
l
The battery only charges if the main switch is
in position 1.
l
The battery charger is in the front right
compartment.
5. Start the remote control and make contact with
the crane again.
The display on the battery charger gives information about the battery charger and the battery.
Left LED
Charger status & faults
Right LED
Battery status
Short green flash every
5 seconds
24V connected LED off Battery fully charged
or
Battery not connected
Continuous red Fault LED continuous
green
Battery charging 1 A
LED flashing green Charging 0.3 A
LED continuous red Fault in the battery
60 U.C30e.00.00.EN Version
