Hologic QDR 4500 - Figure 1-4. QDR 4500 Block Diagram (Scanner Unit)

To Next Page

To Previous Page

Section 1 - Introduction

1-5

DISTRIBUTION

CONTROL

PANEL

CONTROLLER

TZ DRIVE

MOTOR

CONTROLLER

TX STEPPER

MOTOR

DRIVER

TY STEPPER

MOTOR

DRIVER

AR STEPPER

MOTOR

DRIVER

AY STEPPER

MOTOR

DRIVER

PEDESTAL LEFT

MOTOR AND

POSITION ENCODER

C_ARM CARRIAGE

MOTOR AND

POSITION ENCODER

C_ARM ROTATION

MOTOR AND

POSITION ENCODER

PEDESTAL RIGHT

MOTOR AND

POSITION ENCODER

TABLE LEFT/RIGHT

MOTOR AND

POSITION ENCODER

TABLE IN/OUT

MOTOR AND

POSITION ENCODER

CONTROL PANEL

TO/FROM C-ARM INTERFACE (FIGURE 1-5)

TO/FROM

COMMUNICATION

CONTROLLER

15/24V

EMERGENCY

LEFT/RIGHT PEDESTAL

28V DC

TO/FROM

POWER

MODULE

Figure 1-4. QDR 4500 Block Diagram (Scanner Unit)
